3410

MODEL : 3410

Heavy Duty IR thermometer, Dual Laser, with Type K thermocouple port and hard case

  • Stem Lengths: 1⅝, 2½, 2¾, 4½, 7½, 10½, 13½, 16½, 22½”
  • Stem Diameter: .375″ standard .250″ optional
  • Connection: 316SS Tri-Clamp fitting sizes ¾*, 1½**, 2, 3, and 4″
  • External Reset: Easy to calibrate by inserting a hex key into reset opening
  • Material: 316SS wetted parts, 304SS non-contact parts
  • Hermetic seal: Per ASME B40.3 dustproof and leakproof
  • Dial: True Anti-Parallax dial, easy-to-read from any angle, minimizes reading errors Anodized aluminum with large black numbers and graduations
  • Lens: Glass, tempered glass, safety glass, acrylic, or polycarbonate
  • Bimetal Coil: Helix coil is silicone coated on ranges below 500°F for vibration dampening and to maximize heat transfer and response time
  • Accuracy: ±1% full span per ASME B40.3 Grade A Over
  • Temperature: Up to 250°F 100%; 250°F to 550°F, 50%; 550°F to 1000°F, continuous use up to 800°F,
  • Limits: intermittent use over 800°F Surface Finish: All wetted parts, max. 32 micro-inches (.80 microns) on stem, weld radius, and underside of flange, per 3-A Sanitary Standard 74-07 requirements
